Product Overview

The Automatic Paper Sleeve Machine is engineered for inline or standalone application of paper bands and trays, cartons, and containers. Designed for high-speed paper conversion lines, it integrates feeding, folding, positioning, and sealing into a single automated sequence. This machine processes kraft paper, art paper, and recyclable coated paper ranging from 100 to 300 GSM, meeting zero-plastic retail packaging regulations without sacrificing line throughput.

Die-Cut Paper Sleeve Making Machine
The Die-Cut Paper Sleeve Making Machine integrates reel/sheet feeding, flatbed or rotary die-cutting, precision folding, and adhesive application into a continuous inline workflow.
Kraft Paper Cup Sleeve Making Machine
The Kraft Paper Cup Sleeve Making Machine automates the conversion of reel stock into finished, insulated corrugated and kraft paper cup jackets.
Ripple Paper Cup Sleeve Making Machine
The Ripple Paper Cup Sleeve Making Machine converts flat paper rolls and corrugated medium into custom-branded, thermal-insulating cup sleeves.
Corrugated Paper Cup Sleeve Making Machine
The industrial automatic corrugated paper cup sleeve making machine converts pre-printed paper blanks and corrugated inner webs into insulated ripple cup sleeves.
High-Speed Paper Sleeve Making Machine
The HM-Series High-Speed Paper Sleeve Making Machine automates the inline feeding, creasing, cold/hot-melt gluing, folding, and cutting of flat paper blanks into finished protective sleeves.
Automatic Paper Cup Sleeve Making Machine
The Automatic Paper Cup Sleeve Making Machine converts pre-printed, die-cut paper blanks into corrugated, double-wall, or ripple insulating cup sleeves at sustained industrial speeds up to 180

Technical Specifications

Parameter	Specification
Applicable Products	Food trays, cosmetic boxes, soap sleeves, cup multiplex
Band/Sleeve Width	30 mm - 250 mm (Customizable)
Max. Operating Speed	Up to 120 cycles/minute (depends on material and size)
Paper Material GSM	100 GSM - 300 GSM kraft / coated paper
Sealing Method	Ultrasonic welding / Thermal sealing
Electrical Supply	380V, 3-Phase, 50/60Hz (configurable)
Total Power Consumption	3.5 kW
Machine Dimensions	L 1800 mm x W 950 mm x H 1450 mm
Net Weight	650 kg

Key Features

Servo-Driven Feed Mechanism: Dual servo motors control paper feeding and tensioning, holding positioning accuracy to within +/-0.5 mm at maximum speed.

Quick-Change Tooling: Modular forming channels enable format changeovers in under 15 minutes without external hand tools.

Ultrasonic Sealing Unit: Applies clean, instant seals without adhesive curing time, eliminating glue residue and warm-up delays.

PLC & HMI Control System: Industrial touchscreen interface stores up to 50 job profiles for rapid parameter recall across recurring production batches.

Jam Detection Sensors: Optical sensors track paper flow at critical feed points, triggering automatic halts to prevent material pile-ups and film/paper tear.

Applications

Ready-Meal Packaging

Securing cardboard sleeves onto modified atmosphere packaging (MAP) trays for chilled ready meals.

Bakery & Confectionery

Banding folding cartons and bakery boxes for retail shelf display.

Cosmetics & Personal Care

Applying branded paper wraps around soap bars, cosmetic palettes, and gift boxes.

Beverage Multipacks

Bundling canned or bottled goods with structural paperboard sleeves as an alternative to plastic rings.

Customization

Conveyor Integration

Height-adjustable infeed and outfeed extensions to interface directly with existing thermoforming or filling lines.

Extended Magazine

High-capacity vertical paper stacker for uninterrupted operation during high-volume runs.

Coding Integration

Direct mounting brackets for thermal inkjet (TIJ) or laser coders to print batch numbers and barcodes during banding.

Voltage Adaptation

Custom electrical schematics built to local industrial standards (e.g., UL/CSA compliance wiring configurations).

Manufacturing & Quality Control

01/

Machining Precision: Structural frames are CNC-milled from solid steel plates to eliminate vibration at operating speeds exceeding 100 cycles per minute.

02/

Component Traceability: Critical motion control components, including linear guides and pneumatic cylinders, are sourced from certified industrial brands (Festo, SMC, Schneider).

03/

Factory Testing Protocol: Every machine undergoes a continuous 48-hour dry run test followed by a 4-hour live material test using customer-supplied paper stock prior to crating.

04/

Compliance Standards: Built in accordance with CE machinery directives, utilizing interlocked safety guards and emergency stop circuits wired to ISO 13849-1 safety standards.

Installation & After-Sales Support

Documentation Package: Complete delivery includes electrical schematics, pneumatic diagrams, PLC logic maps, and a part-replacement catalog in English.

Commissioning Options: On-site installation support by mechanical engineers available, supplemented by remote video diagnostics via secure industrial gateways.

Wear Parts Availability: Standard replacement items (heating elements, cutting blades, drive belts) stocked in regional warehouses for dispatch within 48 hours.

Packaging & Delivery

Export Crating

Vacuum-sealed in moisture-barrier foil with desiccant packs, secured inside fumigated plywood crates compliant with ISPM 15 standards.

Shipping Dimensions

Palletized layout engineered to fit standard 20-foot container door clearance without requiring complete disassembly.

Lead Time

Standard configurations ship within 30 to 45 business days from receipt of deposit and sample substrate confirmation.

FAQ

Q: What is the minimum and maximum paper GSM the machine accepts?

A: The standard feed mechanism handles substrates from 100 GSM to 300 GSM. Materials outside this range require custom feed roller calibration.

Q: How does the machine seal the paper sleeve?

A: It uses an integrated ultrasonic sealing head that welds the overlap instantly through high-frequency mechanical vibrations, avoiding glue setup time and drying delays.

Q: Can this unit tie into our existing downstream packaging line?

A: Yes. The machine features digital I/O handshaking signals to synchronize feed rates with upstream tray denesters and downstream case packers.

Q: What is the average time required for a size changeover?

A: Operators trained on the modular tooling system complete a full format change in 10 to 15 minutes.

Request a Quote

To configure a Paper Sleeve Machine matching your specific tray dimensions and line speed requirements, submit the parameters below to our engineering desk:
Target substrate material and GSM
Sleeve/Band unfolded dimensions (length x width)
Required operating speed (cycles per minute)
Infeed/outfeed conveyor height requirements
