Product Overview

The Paper Bucket Machine is an automated vertical forming system engineered for high-volume production of large-capacity round paper containers. It integrates automatic paper feeding, multi-stage bottom punching, ultrasonic or hot-air sealing, knurling, and rim curling into a continuous workflow. Built for continuous industrial operation, this equipment processes heavy-duty PE-coated paperboard to deliver leak-proof packaging for food service and industrial supply chains.

Target Output: 40-80 pcs/min (variable by bucket diameter and GSM)
Container Capacity: 24 oz to 170 oz (interchangeable mold sets)
Raw Material: Single or double PE-coated paperboard (200-450 GSM)

Square Paper Bucket Making Machine
The Square Paper Bucket Making Machine is an automated forming system designed to convert pre-printed and die-cut paper blanks into leak-proof square and rectangular paper containers.
PE-Coated Paper Bucket Making Machine
The PE-Coated Paper Bucket Making Machine automates the production of large-capacity paper containers—ranging from 35oz to 170oz—from single or double polyethylene-coated paperboard.
Popcorn Paper Bucket Making Machine
The Industrial Popcorn Paper Bucket Making Machine is an automated converting system engineered for high-volume production of cylindrical and tapered paper containers, specifically configured for
Ice Cream Paper Bucket Making Machine
The ZB-Series Automatic Ice Cream Paper Bucket Making Machine is engineered for high-speed, precision forming of large-capacity paper containers, specifically ice cream tubs, yogurt buckets, and soup
High-Speed Paper Bucket Making Machine
The High-Speed Paper Bucket Making Machine is engineered for high-volume automated production of large-capacity paper containers, including fried chicken buckets, ice cream tubs, popcorn containers,
Automatic Paper Bucket Making Machine
The industrial automatic paper bucket machine forms single-PE and double-PE coated paper containers ranging from 16oz to 85oz. Built for continuous 24/7 manufacturing plants, this unit integrates

Technical Specifications

Specification Item	Industrial Standard Model (PBM-130)	Heavy-Duty Large Model (PBM-170)
Bucket Capacity Range	24 oz - 85 oz	60 oz - 170 oz
Rated Production Speed	60 - 80 pcs/min	40 - 60 pcs/min
Raw Material Range	220 - 380 GSM PE-coated paper	280 - 450 GSM PE-coated paper
Sealing Method	Swiss Leister Hot Air Heater / Ultrasonic	Swiss Leister Hot Air Heater
Bottom Paper Feeding	Automatic roll/die-cut sheet feed	Automatic die-cut sheet feed
Total Power Consumption	12 kW (3-Phase, 380V, 50Hz / Customized)	18 kW (3-Phase, 380V, 50Hz / Customized)
Machine Dimensions	3200 x 1400 x 1900 mm	3800 x 1600 x 2100 mm
Total Machine Weight	2,800 kg	4,200 kg

Key Features

Dual-Station Bottom Heating and Curling: Utilizes a mechanical cam-driven indexing mechanism combined with dual thermal heating stages to ensure complete fusion of the bottom disc and side wall, eliminating bottom leakage risks under high-fat or liquid loads.

Open-Type Cam Indexing Unit: Employs a high-precision Japanese precision indexer (Roller Gear Cam) running in an enclosed oil bath. This minimizes mechanical backlash and maintains positioning accuracy during high-speed operation.

PLC & Servo Control Architecture: Controlled via an industrial PLC and touch-screen HMI. Integrated photoelectric sensors monitor paper jam, empty bottom, and misfeed conditions, triggering automatic machine stoppage to prevent mold damage.

Modular Ultrasonic Sealing System: Integrates ultrasonic side-sealing generators for double-PE coated paperboard, avoiding glue usage and reducing setup time compared to traditional thermal-wire heating elements.

Applications

Commercial Food Service

Popcorn buckets for cinemas, fried chicken barrels for fast-food chains, and large salad/soup bowls.

Frozen & Dairy Sector

Bulk ice cream tubs and multi-liter dessert containers.

Industrial & Retail Packaging

Paper packaging buckets for pet food, laundry detergent powders, and hardware components.

Customization

Mold Interchangeability

Quick-change mold sets allow a single machine frame to produce varying bucket top diameters (from 110mm to 200mm) by swapping the forming horn, knurling ring, and bottom-sealing die.

Voltage & Electrical Compliance

Control panels configured to local electrical codes, including safety interlocks, UL-listed wiring components, and transformer integration for 220V, 440V, or 480V environments.

Integrated Peripheral Add-Ons

Optional configuration for inline inspection systems, automatic stacker-conveyors, and vision-based defect sorting.

Manufacturing & Quality Control

Machining Precision

Main frames and heavy-duty rotary tables are machined on CNC boring and milling centers in a single setup, holding structural parallelism tolerances within 0.02 mm to prevent premature bearing wear during continuous runs.

Component Traceability

Critical drive shafts utilize heat-treated 40Cr alloy steel; gears undergo high-frequency quenching to HRC 55-58. Pneumatic actuators and linear guides source directly from SMC and HIWIN.

Factory Testing Protocol

Every machine undergoes a mandatory 72-hour continuous dry-run test followed by an 8-hour load test using client-supplied raw material samples prior to crating. Dimensional tolerance and leakage testing reports are archived for each serial number.

Installation & After-Sales Support

Documentation Package: Supplied with comprehensive English manuals, including electrical schematics, pneumatic circuit diagrams, PLC ladder logic backup, and a detailed spare parts catalog with OEM part numbers.

Commissioning Support: Remote video engineering support provided standard. On-site installation, mechanical tuning, and operator training by senior technicians available upon request.

Spare Parts Inventory: Common wear items—such as heating elements, silicone rollers, proximity sensors, and springs—are stocked in central warehouses for immediate dispatch via DHL/FedEx.

Packaging & Delivery

Export-Grade Packaging

Secured on a fumigated solid-wood skid, wrapped in waterproof multi-layer VCI anti-rust film, and sealed inside a heavy-duty plywood crate compliant with ISPM 15 standards.

Shipping Logistics

Containerized loading (20GP or 40HQ) with internal steel-cable bracing to prevent shifting during ocean freight. Port of loading: Ningbo/Shanghai, China. Typical lead time: 35-45 days from deposit receipt.

FAQ

Q: What is the minimum paper GSM required to prevent bucket collapse?

A: For standard 85 oz popcorn buckets, a minimum of 320 GSM single-PE paperboard is required. For industrial or high-moisture applications, 380-420 GSM double-PE coated stock is recommended to maintain stacking strength and radial rigidity.

Q: Can this machine process water-based biodegradable coated paper?

A: Yes. The temperature controllers and hot-air sealing parameters are adjustable to accommodate aqueous dispersion-coated papers, provided the softening point of the eco-coating is verified during preliminary sample testing.

Q: What is the average tooling changeover time between different bucket sizes?

A: With a trained two-person maintenance crew, changing the forming mold, bottom plate feed track, and knurling die takes approximately 90 to 120 minutes.

Q: How is the bottom leakage issue eliminated during high-speed runs?

A: Leakage is prevented through three combined parameters: precise mechanical pressure from the bottom-knurling cam, accurate pre-heating of the bottom rim, and consistent sealing temperature control managed via PID feedback loops tied to solid-state relays.

Request a Quote

To receive a formal quotation tailored to your production requirements, please provide the following parameters:
Target Container Specifications: Top diameter, bottom diameter, height, and capacity (oz/liters).
Paper Specification: Grammage (GSM), PE single/double coating, or biodegradable coating type.
Target Production Volume: Expected output per shift or per month.
Destination Port: For accurate CIF freight estimation or FOB pricing.
